Certificate of Utility Model Patent
For the Electronic Cigarette Pressure Sensor ,We obtained a Certificate of Utility Model Patent on the year of 2014.
The utility model discloses a patch of nonflammable electronic cigarette controller, involved in electronic cigarette technology, including a capsule open at one end, and at the bottom of the capsule is provided with suction hole; The inner cavity of the capsule is mounted with vibration membranes, the gas channel is provided between the vibration membranes and the suction hole; in the opening side of the capsule is mounted with PCB board , one side of the PCB board is connected to the vibration membranes to form a cavity, the other side of the PCB board has pad for electrical connection with the end product, the pad is provided with three welding electrodes which is triangular distributed on the pad . The utility model SMD nonflammable electronic cigarette controller solved the problem of finished electronic cigarettes controller low acceptance rate in the prior art. The utility model SMD nonflammable electronic cigarette controller can be high temperature reflow, low processing difficulty, high production efficiency and product qualification rate.
